● 8 10/100BASE-TX RJ45 ports, 2 10/100/1000BASE-T RJ45 ports ;
● 6KV lightning protection;
● Up to 8 ports of IEEE 802.3af/802.3at devices powered;
● Supports PoE Power up to 30.8 watts for each PoE port;
● Each port supports 51V DC power to PoE Powered Device;
● 99-watt PoE budget;
● Extend Ethernet mode with 250m transmission distance;
● Plug and play design, no configuration required;

Lightning Protection 6kV

The ports and embedded power can provide lightning protection of up to 6kV. It also provides PSE shortcircuiting protection, PoE overloading, power over temperature, over voltage and surge current protection.

PoE+ and Dual Gigabit Uplink

Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides PoE power of up to 30W each port and up to 99W the whole device. The two gigabit uplink ports are capable for cascade connection of more devices.

250 Meters Transmission

With 8-pin and the professional network extension technology, the transmission distance of power and data can be up to 250 meters, which can work in place of network extender or some optical fiber to expand the network without additional cost.
